Features
HornetTM Frac System uses Mechanical Casing Collar Locator to position the tool string at the planned stage, run in the work string to set the packer and isolate the frac zones.

The flow fluid through carbide nozzles is greatly restricted, and as per Bernoulli's theorem, the high-pressure sand-laden fluid is converted into high-velocity fluid to cut through the casing and cement. When the perforations are complete, pressure is applied down the annulus to perform the fracture. After executing the fracture treatment, pull up the coiled tubing, unset the packer and position the string at the next stage, run in the coiled tubing string and set the packer, repeat the steps to perform the fracture on all the stages.

HornetTM Frac System can execute fracture treatment very well on the horizontal thin reservoir, and it is a practical option for re-fracture in unconventional oil and gas reservoir, such as tight gas reservoir, coalbed methane, and shale gas.

For the realization of HornetTM Frac System on Coiled Tubing, Jereh provides:
External Grapple Connector Mechanical and Hydraulic Disconnect
External Grapple Connector Mechanical and Hydraulic Disconnect

Centralizer Sand Jetting Sub
Centralizer Sand Jetting Sub

Balance Valve Lower Packer
Balance Valve Lower Packer

Mechanical Casing Collar Locator Guide Shoe
Mechanical Casing Collar Locator Guide Shoe
